9''/10'' Stereo Car Radio with 4G+WIFI, 8 Cores CPU, BT 5.0 Module, Multicolor Selection, Fast Turn On Speed
Specification:
| Model | TS10 | TS18 | TS7 | T3L |
| Internet | 4G+WIFI | 4G+WIFI | WIFI | WIFI |
| CPU | 8 cores 1.8GHZ(ARM Cortex A75 ARM Cortex A55) | 8 cores 1.6GHz(CortexTM A55) | 4cores 1.3GHz(ARM Cortex-A7) | 4cores 1.2GHz(ARM Coretex-A7) |
| GPU | MaliG523EE Frequency reachable 614.4MHz | PowerVRFentale GE8322 Frequencyreachable550MHz | SinglecoreARM MaliT820,upto600MHz | Mail400Mp2 Frequencyreachable400MHz |
| Reception | Radio:7708 | Radio:7708 | Radio:8035 | Radio:8035 |
| OS | Android10.0 | Android10.0 | Android 8.1 | Android 4.4 |
| Screen | 1280*720 | 1280*720 | 1280*720 | 1280*720 |
| Carplay/Auto | CarPlay+Android Auto (Wired+Wireless) | CarPlay+Android Auto (Wired+Wireless) | Optional | Optional |
| BT module | 5.0 | 5.0 | 4.0 | 4.0 |
| Fullav output | USB plug-in | USB plug-in | USB plug-in | USB plug-in |
| DSP | have | have | have | have |
| RDS | have | have | NO | Optional |
| 360 panoramic view | Optional | Optional | Optional | Optional |
The core board is a built-in 4G network core board developed based on the Spreadtrum UIS7862 chip (8-core 2 * A75+6 * A55 processor, with a main frequency of up to 1.8GHz: GPU: Mali-G52 3EE, and a frequency of up to 614.4MHz). It is a cost-effective 4G Android overall solution, making the car system more distinctive. Introduction to featured features:
1. Supports Android 10.0 system
2. Supports 4G full network connectivity
3. Supports 1 SD card interface (if another SD card needs to be inserted, USB conversion is required, HS8823 is recommended)
4. Supports 2-way SIM card interface
5. Supports 1 USB OTG (additional USB interface requires HUB extension). 6. Supports 1080P hardware decoding
7. Maximum support 2400x1080@60Hz Resolution display screen driver (LVDS/MIPI output).
8. Supports USB interface camera for driving recorder recording and storage
9. Support speech recognition
10. Supports Android or Apple smartphone connectivity
11. Integrated positioning module, capable of supporting GPS, GLONASS, and BeiDou positioning systems
12. Supports quick reverse display with rear view camera
13. Support AHD high-definition camera and 360 panoramic AHD input
14. Support WIFI 2.4G&5G frequency bands and WIFI hotspots
15. Support capacitive screen with more than 5 touch points
16. Bluetooth 5.0 supports Bluetooth phone books, A2DP, as well as external Bluetooth auxiliary devices such as Bluetooth OBD, mouse, controller, keyboard, etc
17. Lower radiation interference, resulting in better radio reception effect
19. Supports both wired and wireless connectivity on Apple phones
|
|
